Description
Fashionable styled
European fashionable styled streamline appearance
Special for Van
Special for Van, ambulance vehicles and truck driving cabin
Low noise
More cooling capacity, more cooling air, low noise
Long life products
Pro-active service, reasonable price, and long life products
Parameter
Model | TCA-40 | |
Cooling capacity | 4200W | |
Voltage | DC12V/24V | |
Condenser | Type | Copper pipe & Aluminum Foil fin |
Fan Qty | 2 | |
Air flow Volume | 680m³/h | |
Evaporator | Type | Copper pipe & Aluminum Foil fin |
Blower Qty | 1 | |
Air flow Volume | 850m³/h | |
Evaporator blower | Double axle and centrifugal flow | |
Condenser fan | Axial flow | |
Compressor | 5H14, 138cc/r | |
Refrigerant | R134a, 0.9Kg | |
Mounting position & driven mode | Rooftop mounted & mono-block, vehicle engine driven | |
Dimensions (mm) | Evaporator | 701×695×180 |
Condenser | ||
Applicable vehicle type | Truck cabins, Engineering vehicles | |
Purchase Guide
Model: TCA-40 is mainly design for truck driving cabins and construction machinery, such as: Bulldozer,Forklifts,Earth Moving Equipment, excavator, road roller and so on.
For the whole air conditioning system, do not remove casually, in case of refrigerant leaking.
Cleaning fouling regularly in the surface of the condenser, in case of the decline of refrigeration effect.
